Description
- Rated Power: 2200W (2.2KW)
- Battery System Voltage: 24VDC
- Solar Charge Controller: Built-in MPPT with a maximum solar charge current of 60A
- Maximum PV Array Power: 1600W
- Inverter Efficiency: 90%~93%
- AC Input Voltage Range: 170~280VAC (UPS mode) / 90~280VAC (APL mode)
- Waveform: Pure sine wave
- Transfer Time: 10ms (UPS mode) / 20ms (APL mode)
- Protection Features: Overload, short circuit, and deep discharge protection
- Additional Features: Cold start function, USB, RS485, CAN monitoring, optional WiFi remote monitoring, and compatibility with generator
